Work Bigger with New GEHL Large-Frame Loaders

GEHL is helping contractors take on big jobs, faster, with its new powerful line of large-frame skid steers and compact track loaders (CTLs). With five models to choose from, GEHL designed these machines to provide functionality with a modern look that emphasizes the size, strength and performance needed for tough construction jobs.

Not only do these machines provide big power, but they are also built to last and help lower the total cost of ownership over their life span.

The five new models include:

• The V325 Skid Steer, offering 72 horsepower and 3,250 pounds rated operating capacity
• The V335 Skid Steer, providing 100 horsepower and 3,350 pounds rated operating capacity
• The V360 Skid Steer, with 114 horsepower and 3,600 pounds rated operating capacity
• The VT335 CTL, delivering 100 horsepower and 3,350 pounds rated operating capacity
• The VT360 CTL, offering 114 horsepower and 3,600 pounds rated operating capacity

Powerful performance
The new large-frame skid steers and CTLs have load-sensing hydraulics to reduce fuel usage without losing power and minimize machine stress, along with a class-leading auxiliary hydraulic flow for operating heavy attachments — with the option for standard flow rates (up to 25 GPM and 3,450 PSI) and high flow rates (up to 40 GPM and 3,450 PSI). To ensure safe attachment use, GEHL designed the machines with variable rate flow that the operator can adjust according to each attachment’s requirements.

Each large-frame loader offers an exceptional bucket breakout force of 10,624 pounds and lift arm breakout force of 7,041 to 7,116 pounds. Built with vertical lift arms and a hinge pin height up to 136 inches, contractors gain higher lift load capacity, optimal truck loading and stable material handling so they can operate the machines with confidence.

With hydraulic horsepower up to 50.3 HP and an optional hydraulic boost to 80.5 HP, these machines are proven to be among the most powerful large-frame loaders in their class.

Designed for optimal function and comfort
The new large-frame skid steers and CTLs from GEHL offer reliable functionality to operators, along with the comfort they need to work on big jobs.

They include exclusive GEHL technologies likethe IdealTrax track-tensioning system that automatically extends the track to its optimal tension when the operator starts the machine and relieves tension when they turn it turned off — a feature that is now in the in-cab monitor. GEHL has also made the Hydraglide comfort ride control boom suspension standard on these machines to reduce material spills and minimize bouncing to improve operator comfort. An IdealAccess fold-up door makes it easier to enter and exit the machines.

For greater protection and visibility, a unique lift-arm design slopes away from the operator at the top of the arm, allowing the hydraulic lines to either run inside of the arm or underneath it. Plus, each arm is equipped with cast steel timing links to improve attachment operation and ground engaging bucket work with minimal stress on the machines.

Both the large-frame skids steers and CTLs offer a 23% bigger cab that is sealed and pressurized, with an adjustable workstation that includes pilot joysticks that move with the seat to the operator’s preference and armrests that adjust independently. A 7-inch color display with defined images and graphics and an exclusive back-lit keypad near the right armrest adds to the in-cab versatility. These features provide operators with intuitive control of the machines and offer maximum comfort even during long workdays.

Additional features
GEHL has incorporated additional features to support safe operation and reliable performance. Standard front LED work lights with time delay illuminate the area around the machine and provide operators with ample time to exit it in the dark. The large-frame loaders come standard with LED rear work light and dual rear tail lights, and have road, hazard and side lights under the lift arm and turn signals as optional features.

Other standard features include a foot pedal for throttle and deceleration based on specific applications, a smart throttle that adjusts engine speeds to start at low idle for fuel efficiency and safety, according to various operating factors.

To learn more about the new large-frame skid steers and CTLs, contact your local GEHL dealer.
